Adopts auto-zero function for easy operation. Serum volume can be confirmed with a serum gauge, allowing capillary tubes to be set without removing the cell holder.
Download CatalogAuto-zero function
Easy capillary insertion
Correction for hemolysis and turbidity
AC adapter (230VAC)
Alarm lamp for abnormalities
Long-life LED light source
| Measurement Method | 2-wavelength differential method (461 nm, 577 nm) |
| Measurement Range | 0 to 30 mg/dL (Total Bilirubin) |
| Interference Correction | 0 to 250 mg/dL |
| Measurement Accuracy | ±5 % |
| Minimum Sample Volume | 50 to 60 μL |
| Display | 3 1/2 digit 7-segment LED |
| Measurement Tube | Hematocrit capillary tube (heparin treated) |
| Light Source | LED |
| Photodetector | High-sensitivity silicon photodiode |
| Power Supply | 230 VAC, 50/60 Hz |
| Dimensions | 280 (W) x 230 (D) x 120 (H) mm |
| Weight | Net 1.0 kg (main unit) |
| Standard Solution (ABY) | 2 bottles |
| Capillary Tube (Heparin treated: Red) | 1 case (100 tubes) |
| Capillary Tube (Plain: Blue) | 1 case (100 tubes) |
| Capillary Putty | 1 sheet |
| AC Adapter | 1 unit |
| Power Cord | 1 cord |
| Instruction Manual | 1 manual |
*Specifications and appearance may be changed without notice for improvement.
